Nanoverse Technologies Unveils Advanced Packaging Tools

In a groundbreaking announcement, Nanoverse Technologies Limited (NVT) has launched its new Advanced Packaging line of tools, combining state-of-the-art laser singulation and innovative metrology solutions. This suite of tools is set to revolutionize the packaging landscape, introducing unprecedented speed, versatility, and precision in the industry.

The Advanced Packaging product family comprises four models—5500, 6600, 7700, and 9900—all built on a unified platform architecture that ensures fleet-wide tool compatibility. This alignment across different models simplifies deployment and adoption for manufacturers looking to enhance their production efficiency.

Industry-Leading Laser Technology

The flagship model, NVT 7700, exemplifies the fusion of advanced laser scribing technologies with high-precision metrology. Integrated with ultrafast laser processing capabilities, the system boasts the capability to achieve die break strength that is 2 to 3 times greater than existing processes. Excitingly, it can process up to 30 wafers per hour with an accuracy of less than 3mm and a GRR (gauge repeatability and reproducibility) of less than 300nm.

The versatility of the NVT 7700 allows it to execute various tasks simultaneously—scribing, dicing, metrology, coating, cleaning, and post-coat baking—thereby streamlining operations and reducing lead times. Furthermore, its software architecture supports recipe-driven automation and is designed to be fully compliant with SEMI standards, facilitating a smooth integration into existing production lines.

Tailored Solutions for Different Needs

The NVT 6600 family retains the pinnacle innovations of the 7700 but is optimized for environments where integrated metrology may not be as critical. It maintains the essential capabilities like coating, cleaning, and dicing while offering a smaller footprint and higher throughput suitable for various production settings.

On the other hand, the NVT 5500 is a standalone metrology inspection system featuring a patented phase-based white light approach. This high-speed, high-resolution system is designed for whole wafer scanning, providing simultaneous 2D and 3D data without the cumbersome image-stitching process that many conventional systems require. This feature enhances the detection of bumps, pads, debris, and other defects across a broad range of substrate surfaces.

Looking Toward the Future

Scheduled for launch in mid-2026, the NVT 9900 platform represents the next step in laser-based singulation technology. This model incorporates a dual-laser setup, enabling high-speed and high-quality scribing and dicing, thus optimizing the die prep process. The versatility of having different wavelengths, pulse widths, and energy settings for the lasers ensures that customers can customize their singulation processes to meet specific requirements, making it a perfect alternative or complement to plasma dicing.

CEO Jeff Albelo of NVT sums it up beautifully: “We now offer real-time process observability coupled with advanced singulation technology for rapid prototyping and high-volume manufacturing. It’s a game changer.” This statement highlights the commitment of Nanoverse Technologies to lead the industry by providing cutting-edge solutions that enhance production capabilities and set new benchmarks for quality and efficiency.

For more insights into the Advanced Packaging line and to learn how NVT can support your advanced packaging roadmap, visit www.nanovtech.com. Structured to foster innovation, NVT continues to redefine what is possible in laser technology and metrology applications across various manufacturing sectors.
