E&R Engineering Unveils Cutting-Edge Solutions at SEMI West 2026
E&R Engineering Corp. (TPEX: 8027) is set to make waves at this year’s SEMI West 2026 conference, taking place from October 13 to 15 at the Moscone Center in San Francisco, California. The company, a recognized leader in semiconductor laser and plasma processing equipment, will showcase their groundbreaking innovations in high-precision laser drilling and advanced encapsulation solutions.
Precision Laser Solutions for Fiber Arrays
One of the highlights of E&R’s presentation will be their high-precision laser drilling technology specifically designed for Fiber Array Units (FAUs). This cutting-edge solution is engineered to meet the growing demand for high-density optical components used in high-speed optical communications and integrated optical systems (CPO). The new FAU laser machining setup supports impressive bandwidths of up to 12.8 Tbps while ensuring drilling accuracy of ±0.5 μm. This five-axis laser control allows for various hole geometries and machining angles, making E&R’s solutions versatile and efficient.
Comprehensive Laser and Plasma Solutions
Addressing challenges posed by AI architectures and high-performance computing (HPC), E&R Engineering introduces a suite of laser processing solutions tailored for advanced 2.5D/3D integrated circuits and high-density substrates. Their capabilities include high-precision laser drilling with a remarkable ±5 μm accuracy and blind via aspect ratios reaching up to 90%. Additionally, they offer high-throughput multi-beam laser marking with ±25 μm precision, thermal-controlled laser cutting, and defined path ABF routing.
This comprehensive suite ensures that customers can integrate laser delamination seamlessly into their conditioning workflows. Alongside this, E&R provides high-stability plasma systems (CPK > 1.33) for surface cleaning and activation, accompanying clients from initial R&D validation to large-scale production deployment.
Reliable Support and Service in the U.S.
E&R places significant emphasis on customer support, operating local service teams across major U.S. semiconductor hubs, including Portland, Arizona, and Texas. Their regional presence is designed to minimize downtime, optimize yield, and accelerate time-to-market for North American semiconductor partners. With quick response times and tailored technical support, E&R ensures that they are always nearby to assist their clientele.
Visit E&R Engineering at SEMI West 2026
Attendees at SEMI West are invited to explore E&R Engineering's booth located in the South Wing, Hall C, Number 2153. Interested parties can also visit their website at
https://en.enr.com.tw/ for more information on proposed solutions.
This event offers a unique opportunity to witness firsthand the innovative laser processing technologies that are shaping the future of the semiconductor industry.
In summary, E&R Engineering is poised to leave a significant mark at SEMI West 2026 with their advanced technologies and commitment to supportive service—redefining standards in the realm of semiconductor fabrication and processing.
