Introduction to the V-571.Z Vertical Translation Stage

In the field of high-precision automation, the demand for advanced motion control systems is ever-increasing. PI (Physik Instrumente), a prominent name in the precision motion control and nanopositioning systems domain, has introduced its latest addition, the V-571.Z vertical translation stage. This innovative product is tailored for various applications, including microscopy, photonics, semiconductor metrology, and optics alignment. With its user-adjustable magnetic counterbalance, the V-571.Z is engineered to handle intricate vertical positioning tasks that require exceptional accuracy and rapid dynamic response.

Key Features and Benefits

The V-571.Z stages stand out due to several key features:

• - Magnetic Counterbalance: The inclusion of a user-adjustable magnetic counterbalance allows the stage to support loads up to 4 kilograms, minimizing the exertion on the motor. This design facilitates efficient, high-acceleration motion, thus enhancing operational capacity without any compromise on accuracy.
• - Compact Design with High Performance: With a slim profile of just 95 mm in body width, the V-571.Z provides superior travel accuracy, flatness, and guiding performance. This compactness enables it to efficiently conduct vertical focusing, scanning, measuring, imaging, and alignment tasks in limited spaces, making it ideal for both laboratory settings and production environments.
• - Direct-Drive Motor Technology: The direct-drive non-cogging linear motor ensures a smooth, friction-free motion, resulting in high dynamics capable of meeting the rigorous demands of modern scientific and industrial applications. The direct connection between the motor and the moving stage eliminates mechanical complications, further enhancing longevity and performance.
• - Ultra-Precision Bearings: The integration of ultra-precision cross-roller bearings ensures the stage delivers smooth and stiff motion with low maintenance requirements throughout its operational life. This contributes to the reliability and durability of the system in various applications.
• - Encoder Options: Users can choose between incremental and absolute encoder options, with models equipped with absolute encoders providing 1 nm resolution. This feature eliminates the need for a homing process at startup, thereby improving operational efficiency and safety significantly.

Versatile Applications

The V-571.Z vertical translation stage is versatile enough to cater to numerous fields:

• - Microscopy: It allows for precise sample positioning and adjustments in imaging applications.
• - Photonics: Useful in applications requiring tight tolerance in light alignment and focusing.
• - Semiconductor Metrology: Ideal for dimensions and alignment in semiconductor devices, ensuring significant accuracy in measurements.
• - Optics Alignment: Facilitates the alignment of optical systems, ensuring optimal performance of sophisticated optical devices.

Advantages Over Alternative Solutions

While PI also offers pneumatic and mechanical counterbalancing solutions, the adjustable magnetic counterbalance principle used in the V-571.Z provides distinct advantages. It is simpler, more flexible, and compact compared to traditional systems. This conversion marks an evolution in the design and execution of positioning systems within advanced engineering and scientific research.

Conclusion

The V-571.Z vertical translation stage is now available through PI’s global sales channels and regional offices. For those interested in witnessing the V-571.Z firsthand, it will be showcased at Photonics West, booth #3517. The latest in PI's motion control technologies promises to enhance precision automation processes significantly, addressing the ongoing challenges faced in the field. This innovation marks a crucial step towards improved nanopositioning solutions, adaptable for various high-tech applications in today’s rapidly advancing landscape.

For more information about the V-571.Z vertical translation stage, you can visit PI’s official website or contact their sales division directly.
